Features:

- 8 layers double-sided PCB board

- 3oz 1.4mm thick power board

- 32bit F051 MCU, 48kHz maximum clock speed

- TDK MLCC Low ESR ceramic capacitors


Specifications:

- Supports up to Dshot600, Proshot, Oneshot, Multishot

- Constant: 55A / Burst: 60A (10S)

- Up tp 48kHz PWM frequency

- Target: IFLIGHT_BLITZ_G3

- BlHeli32 telemetry: Yes

- Firmware Version: 32.9

- Dimensions: 35*13mm

- Current Sensor: Yes

- Input: 2-6S LIPO

- RGB LED: Yes

- Weight: 4.7g

- MCU: G071

- BEC: No


Note:

No additional capacitor needed up to 5S!

But to encounter back EMF and ensure the longevity of your electronics, min. 220uF Cap 35V for 4-5S, 50V for 6S on your main lead!

Оставить отзыв

Пожалуйста, авторизуйтесь или зарегистрируйтесь для написания отзыва

iFlight BLITZ E55 BLHeli32 55A 2-6S Single ESC

  • Бренд: iFlight
  • Модель: iFlight BLITZ E55 BLHeli32 55A 2-6S Single ESC
  • Наличие: 30-60 Дней
  • 2 800 руб
